HS2 trials automotive design tech in bid to cut embedded carbon

by Liam Turner
Computer generated image of the Small Dean Viaduct 10 years post construction

HS2 has announced it is to trial automotive design technology in an effort to reduce embedded carbon by 10%.

In what’s being billed as a “first” for the construction industry, technology originally developed to design and optimise automotive and aerospace structures is being deployed on the UK’s high-speed rail project.

HS2 has teamed up with Leamington Spa-based Altair Ltd, to develop an automated civil engineering design process driven by its software tool.

Altair says its OptiStruct tool can reduce embedded carbon in HS2’s viaducts by up to 10%, as well as shrink viaduct design time from around a month to as little as one hour.

The design technology is similar to that which Altair uses to design components and assemblies within modern aircraft and automotive vehicles to minimise the amount of raw material used.

The firm’s HS2 collaboration team has tested and refined the OptiStruct-driven process for the civil engineering sector.

HS2 says the technology enables engineers to flex a viaduct’s design – for example, the span length between each supporting pier could be increased thereby reducing their overall number.

The technology takes a viaduct’s operational requirements, including the speed, frequency, and braking load of the high-speed trains it will carry throughout its operational life.

It then runs millions of design iterations based on the physical properties of all the materials it will be built with, including concrete and steel, to produce an optimised design.

‘Gamechanger’

HS2’s senior innovation manager, Charlotte Hills, said: “HS2 is the biggest transport infrastructure project in the UK.

“To help build it, we are drawing on the technology developed for other industries to help deliver the new high-speed rail network and adding value to UK plc by creating new opportunities for innovative companies outside civil engineering.

“Working with Altair as part of our Innovation programme demonstrates the benefits of applying its technology to building HS2, and the potential it offers in the long term as an integral tool to streamline structural designs and reduce embedded carbon by as much as 10%.”


More on HS2:


Tomas Garcia, HS2 head of Civil Engineering Structures, said: “Our innovation project with Altair is a gamechanger – it gives engineers a tool to explore alternative designs that were not previously feasible due to time constraints.

“By cutting development time, running automatically dozens of combinations of the design variables, the technology allows to identify solutions that minimises embedded carbon.”

Altair Ltd’s senior technical specialist, Martin Kemp, said: “Altair’s design and optimisation technologies have been utilised across industry for over two decades.

“However, we seldom see them deployed on structures as large as rail viaducts due to rigorous codes of practice.

“HS2 was determined to remove the barriers to adoption by integrating European Codes of Practice directly into the optimisation process.

“The resulting capability brings cutting edge design and innovation to viaduct designers and opens further adoption in civil structure design.”

HS2 plans to mandate Altair’s technology for designing viaducts and bridges on Phases 2a and 2b for the high-speed rail programme.

Image: CGI of the HS2 Small Dean Viaduct 10 years post construction. Credit: HS2
